Torgo CP9
Most demanded version
Pick a Color
Performance
Kilometers of Range
100 km (varies with use and version)
Static Roll-Over Angle
43º
Top Speed
70km/h
Dynamic Roll-Over Angle
30º (Depends on Version)
Charging Time
3h (22kW)
40 min (60kW)
40% Gradient of Slope
Always capable for most of the terrain conditions
60% Gradient of Slope
Capable if adherence allows it
100% Gradient of Slope
Capable for short periods of time, if adherence allows it.
Basic vehicle configurator
Colors
Views
Complete Equipment
Specs CP9
ENGINE
Type
Brushless DC
Power Units
2
Nominal Output
180kW (245cv)
Peak Output
328kW (440cv)
Nominal Torque
800Nm
Peak Torque
2400Nm
Refrigeration
Liquid Cooled
BATTERY
Type
Modular Li-iOn BP
Capacity
72 kWh
Protection
IP67
Safety Requirements
R-100
Refrigeration
Liquid Cooled
WEIGHT
Máximum Permissible
(5500 - 6400) kg
Load Capacity
(1100 - 2000) kg
Front Axle Load
3200kg
Rear Axle Load
3200kg
Maximum Towable
3500kg
SUSPENSION
Type
Multilink Fully Independent Suspension
Damping
Springs + Shock Absorbers, with Anti-Roll Bar in the front axle (optional in the rear axle)
Suspension Travel
200mm
SEATS
Number of seats
9 (Depends on the variant or application)
Driver Seat
Driver Seat
Co-Driver Seats
Fixed
Passenger Seats
Fixed with lateral-support headrest
Options
Options
More than a vehicle, an investment in the future of green mobily
Ideal for businesses and public administrations. TORGO offers durability, autonomy and superior performance, setting a new standard in sustainable mobility.
